Industry-leading performance with Intel® Core i technology. The EFC-22 features options for a range of processors with on-board graphics, ensuring the right performance level is specified for your application while retaining cost-effectiveness.
The EFC-22 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
The EFC-22 has an operating temperature range of -5°C to 55°C, providing extended operational life in extreme temperatures and environments.
The 9-30V DC input power provisions for fluctuating power sources, achieving compatibility with a broader variety of applications and larger equipment installations.
High reliability, industrial-grade components designed for 24/7 operation combined with a robust construction optimises the service life of the EFC-22.
The EFC-22 comes with expansion card slots that provide the flexibility needed for application-specific configurations. We will install, configure and test the complete platform, ensuring total functionality before delivery.
Full out-of-band remote management with Intel Active Management Technology. Monitor, configure and safeguard the EFC-22 through the secured network connection.
| CPU | Intel® Celeron B810 / Core i5-3610ME |
| Memory | 2 x 2GB DDR3 SDRAM (4GB Total), expandable up to 8GB |
| Storage | 1 x 64GB 2.5” SATA SSD, optional 500GB 2.5” SATA HDD |
| Expansion | 1 x PCIe x4 1 x PCI expansion slots add-on card CFast Socket |
| LAN | Dual Gigabit |
| Video | 3 Independent displays: 2 Display port and DVI-D 2 Display port and VGA (EFC-222) |
| I/O | 4 x USB 3.0 2 x USB 2.0 5 x RS232 1 x RS232/422/485 |
| Power Supply | 9-30V DC input |
| Dimensions | 215mm (W) x 114mm (H) x 272mm (D) |
| OS Supported | Windows 7, Linux |
| Vibration | 0.5g |
| Certification | CE, FCC Class A |
| Ordering Information | EFC-221 – embedded fanless computer with Celeron B810 processor EFC-222 – embedded fanless computer with Intel i5-3610ME processor |
