The Captec SRS-01 Rugged Server offers high processing performance in a short-depth 19” rackmount form factor. Featuring expansion to enable a range of additional connectivity such as secure fiber interfaces are available up to 100Gb/s, giving high bandwidth for connecting data around the wider system. Enhanced EMI filtering combined with a rugged aluminum chassis provides a low EMI signature, suitable for use in TEMPEST environments. Captec Rugged Servers are designed, built, and formally qualified to meet your exact specification requirements and required military standards, some of which may include MIL-STD-810H, MILSTD- 461G and DO-160G, for use in challenging defense applications.
To enable a range of additional connectivity, such as secure fiber interfaces available up to 100Gb/s, giving high bandwidth for connecting data around the wider system.
Enhanced EMI filtering combined with a rugged aluminium chassis provides a low EMI signature, suitable for use in TEMPEST environments.
Captec Rugged Servers are designed, built, and formally qualified to meet your exact specification requirements and required military standards, some of which may include MIL-STD-810H, MILSTD- 461G and DO-160G, for use in challenging defence applications.
| CPU | 5th Generation Intel – Intel® Xeon® Silver 4516Y+, 24 Core (2.2/3.7GHz), 45MB Cache |
| Chipset | Intel® C741 |
| Memory | Up to 2TB 3DS ECC RDIMM |
| Storage (External) | 1 x 2.5” or 2 x 2.5” Removable SDD (In a bank of 8 bays for the system) |
| Storage (Internal) | Upto 2 x NVMe drives (M.2 PCIe 5.0) |
| Expansion Shots | 2 x PCIe 5.0 x16 (1 x used by 4 x 1Gb Fiber NIC) |
| Graphic | (1 x used by 4 x 1Gb Fiber NIC) |
| LAN | 4 x 10Gb Fiber (LC / MIL-STD 38999) |
| Service Port | MIL-STD 38999 containing: |
| Video | Integrated ASPEED AST2500 |
