e-Mark compliant fanless vehicle and rail computer with PoE and multiple mini-PCIe expansion capabilities. A rugged construction combined with a wide temperature range, shock and vibration resistance and a small form factor provides a powerful platform for many road, rail and vehicle applications.
Industry-leading performance with Intel® Core i technology. The VRC-210/211/212 features options for a range of processors with onboard graphics, ensuring the perfect balance between performance and budget is achieved for your application.
The VCE-210/211/212 complies to the e-Mark safety regulation, making it ideal for in-vehicle installations.
The VRC-210/211/212 is certified to EN50155 and EN50121, positioning it as highly compatible with in-vehicle and rail environments.
The VCE-210/211/212 has an operating temperature range of -40°C to 80°C, providing extended operational life in applications with challenging temperature demands.
The 9-36V DC input power provisions for fluctuating power sources, achieving compatibility with a broader variety of applications and larger equipment installations.
Customisable expansion with multiple SIM and mini-PCIe slots ensures the VCE-210/211/212 will meet your exact requirements.
The VCE-210/211/212 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
| CPU | Intel Core i3-4010U, 1.7GHz |
| Memory | 2GB DDR3, expandable to 16GB |
| Storage | 2 x 2.5” SATA SSD/HDD hot swappable, RAID 0, 1 |
| Graphics | Intel HD graphics 5000 |
| Expansion | 4 x Mini-Card slots with 1 x SIM Card sockets |
| LAN | 4 x Gigabit LAN Port (M12) with PoE (15.4W per port) |
| I/O | 2 x RS232, 2 x RS232/485 |
| Optional I/O | CAN bus |
| Power Input | 9V – 36V, DC-in |
| Watchdog Timer | Reset: 1 to 255 sec./min. per step |
| Video | 1 x DP, 1 x DVI-D |
| Audio | 1 x DP, 1 x DVI-D |
| Operating System | Windows 7/8, Linux |
| PSU | Optional battery backup kit (10 minutes operation) |
| Mounting | Wall-mount/VESA-mount |
| Dimensions | 250mm W x 55mm H x 150mm D |
| Weight | 1.8kg |
| Construction | Aluminium |
| Operating Temperature | -40oC to 70oC (SSD) |
| Storage Temperature | -40oC to 80oC |
| Relative Humidity | 0% RH – 95% RH |
| Shock | 40g, 11ms |
| Vibration | 2.5g, 5-500Hz |
| Certification | CE, FCC Class A, eMark Compliance, EN50155, EN50121 |
| Ordering Information | VRC-210: Core i3-4010U, 1.7GHz |
