e-Mark compliant fanless vehicle and rail-certified computer with PoE and multiple mini-PCIe expansion capabilities. A rugged construction with a wide temperature range, shock and vibration resistance and a compact form factor provides a powerful platform for road, rail and vehicle applications.
The VRC-213/214 complies to the e-Mark safety regulation, making it ideal for in-vehicle installations.
The VRC-213/214 is certified to EN50155 and EN50121, positioning the platform as highly compatible with in-vehicle and rail environments.
The low power AMD processor keeps upfront and through life costs to a minimum. The low thermal output ensures the VRC-213/214 can be specified with minimal impact on install location.
The VRC-213/214 has an operating temperature range of -40°C to 70°C, providing extended operational life in applications with challenging temperature demands.
The 9-32V DC input power provisions for fluctuating power sources, achieving compatibility with a broader variety of applications and larger equipment installations.
The VRC-213/214 can be configured to meet IP65 rated standards. This enables it to be installed in a wide range of dusty or wet environments, usually unsuitable for embedded platforms.
The VRC-213/214 features a rugged fanless design, combining excellent thermal performance with low weight. The system operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high-reliability.
Customisable expansion with multiple SIM and mini-PCIe slots ensures the VRC-213/214 will meet your exact requirements.
A backup battery kit allows the VRC-213/214 to operate for ten minutes when isolated from other power sources. This ensures critical data is not lost in the event of failure and enables the platform to be shut down safely.
| CPU | AMD G-T56N, Dual Core, 1.65GHz |
| Memory | 2GB DDR3, expandable to 8GB |
| Storage | 1 x 2.5” SATA SSD/HDD, 1 x SATA DO |
| Graphics | On board HD graphics |
| Expansion | 3 Mini Card slots, 1 x SIM Card socket |
| LAN | 2 x Gigabit LAN Port M12 |
| I/O | 1 x RS232 (VRC-213) |
| Optional I/O | 1 x CAN bus (VRC-213) |
| Power Input | 9V – 32V, DC-in |
| Watchdog Timer | Reset: 1 to 255 sec./min. per step |
| Video / Audio | 1 x DVI-I / 1 x Line out (1 x Mic in or Line in optional) |
| Operating System | Windows 7/8/10, Linux |
| PSU | Optional battery kit, 10 minutes operation |
| Dimensions | 250mm (W) x 55mm (H) x 150mm (D) |
| Weight | 1.8kg |
| Construction | Aluminium |
| Operating Temperature | -40°C to 70°C (SSD) |
| Storage Temperature | -40°C to 80°C |
| Relative Humidity | 10% to 95% Humidity, non-condensing |
| Shock / Vibration | 40g, 11ms / 2.5g, 5-500Hz |
| Ingress Protection | IP65 (VRC-214) |
| Certification | CE, FCC Class A, eMark Compliance, EN50155, EN50121 |
| Ordering Information | VRC-213: AMD G-T65N, 1.65GHz |
