Compact, reliable and versatile small fanless embedded computer platform combining considerable processing power with low power consumption. A rugged construction with comprehensive I/O connections and a wide voltage input makes this platform ideal for applications including factory and machine automation, kiosks and remote monitoring.
Industry-leading performance with Intel® Core i technology. The EFC-213/4/5/6 features options for a range of processors with onboard graphics, ensuring the perfect balance between performance and budget is achieved for your application.
Multiple serial and digital I/O capabilities combined with SIM card support, two 2.5-inch storage bays and two mini-PCIe expansion ports ensures the platform will meet your exact requirements.
The 9-36V DC input power provisions for fluctuating power sources, achieving compatibility with a broader variety of applications and larger equipment installations
The EFC-213/214/215/216 has an operating temperature range of -40°C to 55°C, providing extended operational life in applications with challenging temperature demands.
The computer features a rugged fanless design, combining excellent thermal performance with low weight. It operates with no moving parts, ensuring silent operation and improving ease of maintenance to support high reliability.
| CPU | Intel® 4th generation Core i3/i5/i7/Celeron processors |
| Memory / Storage | 2GB DDR3, expandable to 16GB 2 x 2.5-inch SATA SSD/HDD, 1 x CFast, 1 x mSATA |
| Graphics | Intel® HD graphics |
| Expansion | 2 x mini-PCIe slot (full size), 1 x SIM slot |
| LAN / I/O | 4 x Gigabit LAN Ports; optional Mini PCIe wireless modules 6 x RS232/422/485, 6 x USB 3.0, 32 channel programmable DIO |
| Video / Audio | 2 x HDMI, 1 x DP, 1 x VGA / 1 x mic in, 1 x line out |
| Operating System | Win XP/7/8, Linux |
| Input Voltage | 9-36 VDC, optional AC power adapter |
| Dimensions / Weight | 280mm (W) x 70mm (H) x 190mm (D) / 3.8kg |
| Operating / Storage Temperature | Op: -40°C to 55°C / St: -45°C to 80°C |
| Vibration | 3g, 5-500Hz (CFast/SSD) |
| Ingress Protection | IP40 |
| Certification | CE, EN60950 compliance |
| Ordering Information | EFC-213: Celeron; EFC-214: i3; EFC-215: i5; EFC-216: i7 |
